Magnet Field Layout Upgrade

MFR#: 1002700-01-SURSK
TIGER#: TS23305
Original price List Price: $479.28
You Save: $118.92 -25%
Original price $479.28 - Original price $479.28
Original price List Price: $479.28
Current price $360.36
$360.36 - $360.36
Current price $360.36
Add to cart for Lower Price
As low as $/mo.
Apply at Cart
Magnet Field Layout Upgrade
Magnet Field Layout Upgrade - $360.36
$360.36
*Must Purchase 1 for Magnet Field Layout Upgrade

The cart will thereforce automatically set Qty to 1 when you order this product

Free Shipping (USA) Ships Out Within: 14 - 21 Business Days Shipping Date By: 10/28/2023
  • Layout projects and get dimension between points
  • View information and measurement tasks on a total station or data collector
  • Choice of renewal options
  • Optional support for robotic total stations and GNSS receiver
  • Optional Cloud connectivity
  • Layer management and building pad tools
  • Simple layout menus

The Topcon MAGNET Field Layout Maintenance allows survey professionals to continue receiving software upgrades after the standard license has expired. This field software improves building layout by giving you full control of your collected data from survey projects and transfer paper plans into accurate layout.

MAGNET Field Layout allows you to quickly layout survey projects and get dimension between two points. It features layer management and building tools for manual data-entry of building pad perimeters, forms and excavation lines. Regardless of terrain, weather and other jobsite restrictions, you can layout and calculate any point or line on the screen’s live map feature and view a summary of multiple point selections using modern equipment such as a total station or data collector.

Optional Integration with MAGNET Enterprise and AutoCAD 360

With the optional MAGNET Enterprise and integration to AutoCAD 360, surveyors and construction professionals can visualize, edit and share field projects through a secure Cloud-based management tool. This ensures that the latest project information is available online and allows you to connect to any active project, select a field crew and view the field activity and data in real time.

For easy preparation or review of your data, you can exchange project files between MAGNET Field Layout on your data collector and MAGNET Office Layout on your desktop or laptop. You can also transfer data to other CAD software packages easily using industry-standard file formats.  Take advantage of Cloud storage by selecting MAGNET Field Layout Solution Upgrade from the drop down menu in the upper right hand corner of this page.

Work with the Latest Topcon and Sokkia Survey Equipment

Whether you are looking to layout cable runs, building corners or a pipeline, MAGNET Field Layout has a simple user interface that displays layout information and basic measurement tasks on your total station or data collector’s screen. This surveying software was optimized for Topcon and Sokkia’s data collectors and total stations, such as the Tesla,MesaFC-2600SHC2500 data collectors and the CXDXES and OS series total stations.

This Topcon software package comes with MAGNET Field Layout Maintenance.

  • Layout projects and get dimension between points
  • View information and measurement tasks on a total station or data collector
  • Choice of renewal options
  • Optional support for robotic total stations and GNSS receiver
  • Optional Cloud storage capability
  • Turn measurements into graphical data
  • Easy layer management tools help you hide the data you don't want to see or use
  • Building pad tool to manually enter building pad perimeters, forms excavation lines and points
  • Import projects prepared on your desktop
  • Easily enter plan features from paper plans onsite
  • Perform surveys and stake-out reports following construction
  • Simple building layout menus

What’s in the Box

  • Topcon Magnet Field Layout Upgrade

Available Package Options

Package:

  • MAGNET Field Layout 3-Year Subscription
  • MAGNET Field Layout 12-Month Renewal
  • MAGNET Field Layout 12-Month Upgrade for Sokkia
  • MAGNET Field Layout Software Maintenance

Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 20% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

Compatibility
Data Collectors
Tesla, Mesa, FC-2600, SHC2500
Total Stations
CX, DX, ES, OS, PS, and SX
Features
Cloud Storage
Optional
Hardware Requirements
Connectivity
Cloud
