Industrial Assembled Super Duty Air Circulator

by TPI Corporation

MFR#: HDH24GJR

TIGER#: TS58219

List Price: $980.00

You Save: $237.89 -24%

$980.00 - $980.00

List Price: $980.00

$742.11

$742.11 - $742.11

$742.11

Add to cart for Lower Price

As low as $/mo.

Apply at Cart

Industrial Assembled Super Duty Air Circulator - $742.11

$742.11

*Must Purchase 1 for Industrial Assembled Super Duty Air Circulator

The cart will thereforce automatically set Qty to 1 when you order this product

Ships Out Within: 14 - 21 Business Days Shipping Date By: 10/27/2023

Documents

Item Brochure Product Video

Choice of blade size and color
HP: 1/2
2-speed switch
Drop down: 18"
Frame Size: 48
Single-Phase, 120V power
Permanent split capacitor
OSHA standard compliant

The TPI Industrial Assembled Super Duty Air Circulator is one of the best and inexpensive solutions to reduce the risks of heat stress and indoor air pollution in many industrial workplaces. Featuring two-speed switch options, this super-duty circulator offers an 18-inch drop down. Also, it utilizes a Single-Phase, 120-volt power and has a permanent split capacitor.

This TPI super duty circulator comes with a motor that offers a horsepower of 1/2 HP and has a frame size of 48. This TPI air circulator features a 1/2-inch shaft and is totally enclosed and permanently lubricated.

The TPI industrial maximum duty air circulator is made of steel hub/spider aluminum paddle blades and powder-coated steel guards that guarantees the circulator will last for a long time. As an extra feature, this TPI industrial fan is OSHA standards compliant.

Please Note: Pedestals, mounts and other accessories are sold separately.

Configuration Options

The TPI Industrial Assembled Super Duty Air Circulator offers four models that have varying blade sizes and colors.

HDH24GJR: 24" Blade Size, Gray
HDH24JR: 24" Blade Size, Yellow
HDH30GJR: 30" Blade Size, Gray
HDH30JR: 30" Blade Size, Yellow

Choice of blade size and color
2-speed switch option
18-inch drop down
Single-Phase, 120V power
Permanent split capacitor
1/2 HP
Frame size: 48
Shaft: 1/2"
Totally enclosed
Permanently lubricated
Made of steel hub/spider aluminum paddle blades
Powder-coated steel guards
OSHA standard compliant

What’s in the Box

TPI Industrial Assembled Super Duty Air Circulator
User manual
5-year limited warranty

Available Product Options

Blade Size: 24" or 30"
Color: Gray or Yellow

This Product is manufactured to order and cannot be returned. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

Fan

Amps

3.5 (HDH 24-JR, HDH 24-GJR); 4 (HDH 30-JR, HDH 30-GJR)

Blade Size

24" (HDH 24-JR, HDH 24-GJR); 30" (HDH 30-JR, HDH 30-GJR)

Certification

OSHA, Intertek

Cubic Feet per Minute (CFM)

5,600/4,900 (HDH 24-JR, HDH 24-GJR); 6,800/6,000 (HDH 30-JR, HDH 30-GJR)

Fan Type

Industrial circulators

Head Type

Stationary

Shaft Size

1/2"

Speed (Revolutions per Minute)

1,100/800

Velocity Profile (CFM/Area Sq. Ft.)

7,500/260 (HDH 24-JR, HDH 24-GJR); 8,000/270 (HDH 30-JR, HDH 30-GJR)

General

Color

Silver

Dimensions

27" Diameter x 14.5" Depth (HDH 24-JR, HDH 24-GJR); 33.5" Diameter x 14.5" Depth (HDH 30-JR, HDH 30-GJR)

Material

Steel hub / Aluminum paddle blades

Warranty

5-year limited

Weight

44 lbs (HDH 24-JR, HDH 24-GJR); 48 lbs (HDH 30-JR, HDH 30-GJR)

Motor

Frame Size

Horsepower (HP)

1/2

Lubrication

Permanent

Power

1-Phase, 120V

Speed Switch

2-speed

Split Capacitor

Permanent

Mount

Mount Type

Fan only. Mounts sold separately
