Guard-Mounted Direct Drive Exhaust Fan

by TPI Corporation

MFR#: CE10D

TIGER#: TS59281

List Price: $390.00

You Save: $94.67 -24%

$390.00 - $390.00

List Price: $390.00

$295.33

$295.33 - $295.33

$295.33

Add to cart for Lower Price

As low as $/mo.

Apply at Cart

Guard-Mounted Direct Drive Exhaust Fan - $295.33

$295.33

*Must Purchase 1 for Guard-Mounted Direct Drive Exhaust Fan

The cart will thereforce automatically set Qty to 1 when you order this product

Ships Out Within: 14 - 21 Business Days Shipping Date By: 10/24/2023

Documents

Product Manual Item Brochure

Choice of 8 fan size & HP
Great for industrial and commercial purposes
Bolted directly to the wall
Optional use of external shutter
Single-phase, 120V permanent split capacitor motor
Pull chain switch
Rough-in hole size: 1/2”
Made of durable aluminum blades

The TPI Guard-Mounted Direct Drive Exhaust Fan is a robust exhaust fan that is great to use for industrial and commercial purposes. It is commonly used to let humid air pass through from humid rooms and areas. This TPI fan is bolted directly to the wall and gives the operator the option to use the external shutter.

The TPI Direct Drive Exhaust Fan utilizes a single-phase, 120-volt permanent split capacitor motor that is totally enclosed and is permanently lubricated. It features a pull chain switch for easy operation. This TPI direct drive fan also has a rough-in hole size of 1/2-inch which is larger than the fan blade.

This TPI exhaust fan is made of durable aluminum blades and steel spiral wire guards that is long lasting and rugged. As an extra feature, it is made in the USA.

Configuration Options

The TPI Guard-Mounted Direct Drive Exhaust Fan has eight available models that you can choose from. Please select from the drop-down menu above.

CE10D: 10” Fan, 1/12 HP (3-Speed Sleeve Bearing)
CE12D: 12” Fan, 1/12 HP (3-Speed Sleeve Bearing)
CE14D: 14” Fan, 1/8 HP (3-Speed Sleeve Bearing)
CE16D: 16” Fan, 1/8 HP (3-Speed Sleeve Bearing)
CE18D: 18” Fan, 1/8 HP (3-Speed Sleeve Bearing)
CE20D: 20” Fan, 1/4 HP (2-Speed Ball Bearing)
CE24D: 24” Fan, 1/4 HP (2-Speed Ball Bearing)
CE30D: 30” Fan, 1/4 HP (2-Speed Ball Bearing)

Choice of 8 fan sizes & HP
Great for industrial and commercial purposes
Bolted directly to the wall
Optional use of external shutter
Single-phase, 120V permanent split capacitor motor
Totally enclosed
Permanently lubricated
Pull chain switch
Rough-in hole size: 1/2”
Made of durable aluminum blades
Steel spiral wire guards
Made in the USA

What’s in the Box

TPI Guard-Mounted Direct Drive Exhaust Fan
User manual
1-year limited warranty

Available Product Options

Fan Size: 10”, 12”, 14”, 16”, 18”, 20”, 24” or 30”
HP (horsepower): 1/12, 1/8 or 1/4

This Item is made to order, and cannot be returned or cancelled after production

We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

(On select TPI Items where clearly indicated, Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 40% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging)

Fan

Amps

1 (CE10D); 1.1 (CE12D); 2 (CE14D); 2.1 (CE16D); 2.2 (CE18D); 2.3 (CE20D); 2.5 (CE24D); 2.7 (CE30D)

Blade Size

10" (CE10D); 12" (CE12D); 14" (CE14D); 16" (CE16D); 18" (CE18D); 20" (CE20D); 24" (CE24D); 30" (CE30D)

Cubic Feet per Minute (CFM)

Up to 680 (CE10D); Up to 825 (CE12D); Up to 1,520 (CE14D); Up to 2,100 (CE16D); Up to 2,300 (CE18D); Up to 2,925 (CE20D); Up to 3,400 (CE24D); Up to 3,950 (CE30D)

Fan Type

Exhaust fans

Speed (Revolutions per Minute)

Up to 1,560 (CE10D, CE12D); Up to 1,660 (CE14D, CE16D, CE18D); Up to 1,140 (CE20D, CE24D, CE30D)

General

Material

Aluminum blades

Warranty

1-year limited

Weight

11 lbs (CE10D); 12 lbs (CE12D); 17 lbs (CE14D); 18 lbs (CE16D); 19 lbs (CE18D); 34 lbs (CE20D); 38 lbs (CE24D); 42 lbs (CE30D)

Motor

Horsepower (HP)

1/12 (CE10D, CE12D); 1/8 (CE14D, CE16D, CE18D); 1/4 (CE20D, CE24D, CE30D)

Lubrication

Permanent

Power

1-Phase, 120V

Speed Switch

3-speed (CE10D, CE12D, CE14D, CE16D, CE18D); 2-speed (CE20D, CE24D, CE30D)

Split Capacitor

Permanent
