FSP Heavy-Duty Flat Panel Emitter Portable Infrared Heater

by TPI Corporation

MFR#: FSP14121C

TIGER#: TS62245

List Price: $1,439.00

You Save: $349.31 -24%

$1,439.00 - $1,439.00

List Price: $1,439.00

$1,089.69

$1,089.69 - $1,089.69

$1,089.69

Add to cart for Lower Price

As low as $/mo.

Apply at Cart

FSP Heavy-Duty Flat Panel Emitter Portable Infrared Heater - $1,089.69

$1,089.69

*Must Purchase 1 for FSP Heavy-Duty Flat Panel Emitter Portable Infrared Heater

The cart will thereforce automatically set Qty to 1 when you order this product

Ships Out Within: 14 - 21 Business Days Shipping Date By: 10/31/2023

Documents

Product Manual Item Brochure

Choice of watts, type & volts
Heat pattern: 60° symmetrical
High-density medium wave heat
Radiant efficiency: 78.5%
Rugged flat panel emitter
Wiring option: single or 3-phase
Housing: Gold anodized aluminum
Life expectancy: 25,000-hour

The TPI FSP Series Heavy-Duty Flat Panel Emitter Portable Infrared Heater is a rugged heater that produces immense amounts of infrared heat in many concentrated areas. With a 60° symmetrical heat pattern, this TPI portable heater provides a high-density medium wave radiant heat that is perfect for spot heating and other protected outdoor environments.

The FSP Series portable infrared heater offers a 78.5% efficiency and 50% efficiency for the metal sheath elements. This TPI portable infrared heater comes with a rugged flat panel emitter that is commonly used in high-vibration areas. Also, it features a single or three-phase wiring option.

This TPI FSP Series heater has a Gold anodized aluminum housing that guarantees endure harsh environments. The heater element has a 25,000-hour life expectancy that is perfect for long hours of use. As an additional feature, the FSP Series includes a heavy-duty wire guard that is mounted on the reflector.

Configuration Options

The TPI FSP Series Heavy-Duty Flat Panel Emitter Portable Infrared Heater offers 16 models that have different features to suit your needs. Please select your preference from the menus above.

Model	kW	Volts	Phase	BTUs / Hr	1-PH Amp	3-PH Amp	Type	Dimensions (L x W x H)
FSP-1412-1C w/ Cord & Plug	1.45	120 V	1	4,947	12.1	N/A	Stand	25" x 11.5" x 14.5"
FSP-3120-1	3.15	208 V	1	10,749	15.4	N/A		46.26" x 11.5" x 14.5"
FSP-3124-1	3.15	240 V	1	10,749	13.13	N/A
FSP-3127-1	3.15	277 V	1	10,749	11.37	N/A
FSP-3148-1	3.15	480 V	1	10,749	6.56	N/A
FSP-3157-1	3.15	600 V	1	10,749	6.48	N/A
FSP-4320-3	4.3	208 V	1 or 3	14,972	20.67	11.94	Hand Cart	37.5" x 20" x 17.5"
FSP-4324-3	4.3	240 V	1 or 3	14,972	17.91	10.36
FSP-4327-1	4.3	277 V	1	14,972	15.52	N/A
FSP-4348-3	4.3	480 V	1 or 3	14,972	8.96	5.18
FSP-4357-3	4.3	600 V	1 or 3	14,972	7.48	7.48
FSP-9520-3	9.5	208 V	1 or 3	32,414	45.67	26.39		53" x 20" x 17.5"
FSP-9524-3	9.5	240 V	1 or 3	32,414	39.68	22.89
FSP-9527-1	9.5	277 V	1	32,414	19.79	11.44
FSP-9548-3	9.5	480 V	1 or 3	32,414	19.79	11.44
FSP-9557-3	9.5	600 V	1 or 3	32,414	16.52	9.54

Choice of watts, type & volts
60° symmetrical heat pattern
High-density medium wave heat
Radiant efficiency: 78.5%
Metal sheath element efficiency: 50%
Rugged flat panel emitter
Single or 3-phase wiring option
Gold anodized aluminum housing
25,000-hour life expectancy
Heavy-duty wire guard

What’s in the Box

TPI FSP Series Heavy-Duty Flat Panel Emitter Portable Infrared Heater
Heavy-duty wire guard
1-year limited warranty

Available Product Options

Watts: 1.45 kW, 3.15 kW, 4.3 kW or 9.5 kW
Volts: 120 V, 208 V, 240 V, 277 V, 480 V or 600 V
Type: Hard Cart or Stand

This Item is made to order, and cannot be returned or cancelled after production

We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

(On select TPI Items where clearly indicated, Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 40% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging)

Dimensions

Heater

25" L x 11.5" W x 14.5" H, 46.25" L x 11.5" W x 14.5" H, 37.5" L x 20" W x 17.5" H, 53" L x 20" W x 17.5"H

Features

Cart

Optional

Disconnect Switch

Forklift Channels

Pilot Light

Thermostat

General

Housing

Gold anodized aluminum

Recommended Mounting Height

3', 4', 7'

Warranty

1-year limited

Weight

23 lbs, 32 lbs, 46 lbs

Heater

Amps

5.18, 6.48, 6.56, 7.48, 8.96, 9.54, 10.36, 11.37, 11.44, 11.94, 12.1, 13.13, 15.4, 15.52, 16.52, 17.91, 19.79, 20.67, 26.39, 39.68, 45.67

BTU

10,749 BTU, 14,972 BTU, 32,414 BTU

Power Distribution

1-Phase or 3-Phase (wiring)

Voltage

120 V, 208 V, 240 V, 277 V, 480 V, 600 V

Wattage

1.45 kW, 3.15 kW, 4.3 kW or 9.5 kW

Motor

Plug

Grounded plug (FSP14121C Only)
