Commercial Circulator

by TPI Corporation

MFR#: CACU20W

TIGER#: TS58413

List Price: $344.00

You Save: $83.51 -24%

$344.00 - $344.00

List Price: $344.00

$260.49

$260.49 - $260.49

$260.49

Add to cart for Lower Price

As low as $/mo.

Apply at Cart

Commercial Circulator - $260.49

$260.49

*Must Purchase 1 for Commercial Circulator

The cart will thereforce automatically set Qty to 1 when you order this product

Ships Out Within: 14 - 21 Business Days Shipping Date By: 10/28/2023

Documents

Item Brochure Product Video

Choice of blade size, mount & head type
Ideal to use in clean and dry environments
Speed switches: 2 or 3
Single-phase motor, 120V
SJT type-3 conductor, 9’ long cord
Open ventilated motor
HP: 1/4 or 1/3 for Heavy Duty models
Adjustable pole: 43” to 60”

The TPI Commercial Circulator is a durable machine that is ideal to use in clean and dry commercial environments like schools, offices, shops and other commercial establishments. It features two or three-speed switches for easy intensity adjustment. This TPI fan uses a single-phase motor that has a voltage of 120 volts.

This TPI air circulator features a pull chain switch and an SJT type-3 conductor cord that nine feet long which allows the operator to place the fan wherever he wants. It comes with a ball bearing, open ventilated motor that is permanently lubricated. The TPI commercial fan also offers a horsepower of 1/4 or 1/3 for Heavy Duty models.

Designed to last for a long time, the TPI circulator is constructed of a steel hub and aluminum paddle blades. Its guards are covered with durable steel and have retaining clips. Plus, it features an adjustable pole from 43 to 60 inches. In addition, this TPI fan meets OSHA standards.

Configuration Options

The TPI Commercial Circulator has twelve models that offer varying features including blade sizes, mount types, and head type. Please choose from the menu above.

CACU20W: Stationary Head with 20" Blade and Wall Mount (1/10 HP)
CACU20P: Stationary Head with 20" Blade and Pedestal Mount (1/10 HP)
CACU24PO: Oscillating Head with 24" Blade and Pedestal Mount (1/4 HP)
CACU24WO: Oscillating Head with 24" Blade and Wall Mount (1/4 HP)
CACU30WO: Oscillating Head with 30" Blade and Wall Mount (1/4 HP)
CACU30PO: Oscillating Head with 30" Blade and Pedestal Mount (1/4 HP)
CACU24P: Stationary Head with 24" Blade and Pedestal Mount (1/4 HP)
CACU24W: Stationary Head with 24" Blade and Wall Mount (1/4 HP)
CACU30P: Stationary Head with 30" Blade and Pedestal Mount (1/4 HP)
CACU30W: Stationary Head with 30" Blade and Wall Mount (1/4 HP)
CACU30POHD: Heavy Duty Fan with Oscillating Head, 30" Blade and Pedestal mount (1/3 HP)
CACU30PHD: Heavy Duty Fan with Stationary Head, 30" Blade and Pedestal mount (1/3 HP)

Choice of model and head type
Ideal to use in clean and dry environments
2 or 3-speeds
Single-phase motor, 120V
Pull chain switch
SJT type-3 conductor, 9’ long cord
Ball bearing
Open ventilated motor
Permanently lubricated
HP: 1/4 or 1/3 for Heavy Duty models
Steel hub/aluminum paddle blades
Steel coated guards
Adjustable pole: 43” to 60”
Meets OSHA standards

What’s in the Box

TPI Commercial Circulator
Mount
User manual
1-year limited warranty

Available Product Options

Blade Size: 20", 24” or 30”
Mount Type: Pedestal or Wall
Head Type: Stationary or Oscillating
Fan Type: Heavy Duty

This Item is made to order, and cannot be returned or cancelled after production

We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

(On select TPI Items where clearly indicated, Tiger Supplies offers a 30-day return policy from date of shipment for this product, subject to a 40% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging)

Fan

Amps

2.3 (CACU24P, CACU24W); 2.4 (CACU30P, CACU30W); 3.6 (CACU30PHD); 1.45/1.15/1.1 (CACU24PO, CACU24WO); 2.0/1.8/1.6 (CACU30PO, CACU30WO); 3.6/3.02/.94 (CACU30POHD)

Blade Size

20", 24”, 30”

Certification

OSHA

Cord Length

9 feet

Cord Type

SJT type-3 conductor

Cubic Feet per Minute (CFM)

High: 3,400, Medium: 3,100, Low: 2,800 (CACU24P, CACU24W); High: 4,200, Medium: 3,800, Low: 2,500 (CACU30P, CACU30W, CACU30PO, CACU30WO); High: 3,200, Medium: 3,000, Low: 2,800 (CACU24PO, CACU24WO); High: 5,000, Medium: 4,600; Low: 4,200 (CACU30PHD, CACU30POHD)

Fan Type

Commercial circulators

Head Type

Stationary (CACU20P, CACU20W, CACU24P, CACU24W, CACU30P, CACU30W, CACU30PHD); Oscillating (CACU24PO, CACU24WO, CACU30PO, CACU30WO, CACU30POHD)

Velocity Profile (CFM/Area Sq. Ft.)

5,100/230 (CACU30PO, CACU30WO); 5,400/220 (CACU24P, CACU24W); 6,700/240 (CACU30P, CACU30W); 6,700/250 (CACU30PO, CACU30WO); 7,000/250 (CACU30PHD, CACU30POHD)

General

Color

Gray

Material

Steel hub / Aluminum paddle blades

Warranty

1-year limited

Weight

43 lbs, 46 lbs, 48 lbs, 51 lbs, 56 lbs, 63 lbs, 64 lbs, 66 lbs, 68 lbs, 70 lbs

Motor

Horsepower (HP)

1/4, 1/3, 1/10

Lubrication

Permanent

Power

1-Phase, 120V

Speed Switch

2 or 3-speed

Split Capacitor

Permanent

Mount

Mount Type

Pedestal, Wall

Pole Adjustment

43" to 60"
