625 Series Strobe Warning Light

by North American Signal

MFR#: DFS625-A

TIGER#: TS44957

List Price: $135.00

You Save: $29.70 -22%

$135.00 - $135.00

List Price: $135.00

$105.30

$105.30 - $105.30

$105.30

Add to cart for Lower Price

As low as $/mo.

Apply at Cart

625 Series Strobe Warning Light - $105.30

$105.30

*Must Purchase 1 for 625 Series Strobe Warning Light

The cart will thereforce automatically set Qty to 1 when you order this product

COLOR

Ships Out Within: 5 - 7 Business Days Shipping Date By: 10/3/2023

Documents

Product Manual

Choice of 17 models in 5 lens colors
Operating voltage at 12/24V
Running a rated current of 0.9 amperes
Produces 400 to 1,200 candelas/second light output
Features 75 double or quad flash display
Designed with black ABS plastic base and Fresnel lens
Includes permanent, pipe and magnetic

The North American 625 Series Strobe Warning Light has an attention-grabbing display which produces economic bright lights. It operates at 12/24V to 120V AC. It features a light output of 400 to 1,200 candelas per second running at a rated current of 0.2 to 3 amperes.

This 625 series strobe warning light is designed with a black ABS plastic base and Fresnel lens designed with double or quad flash display. It is available in permanent with an optional flange base mount, pipe mount, and magnetic mount which includes a 75-lb pull magnet, 15-inch coiled cord and cigarette lighter plug with a built-in on/off switch.

The series is available in 4.5 to 6-inch dome for more light output. All units are available in Amber, Blue, Clear, Green and Red lens colors.

Configuration Options

The North American 625 Series Strobe Warning Light is available in 17 models. Please select your preference from the drop-down menu above.

DFS625-A: 12/24V, Double Flash, w/ Permanent Mount
DFS625P-A: 12/24V, Double Flash, w/ Pipe Mount
DFS625M-A: 12/24V, Double Flash, w/ Magnetic Mount
DFS625H-A: 12/24V, 6" Lens, Double Flash, w/ Permanent Mount
DFS625HP-A: 12/24V, 6" Lens, Double Flash, w/ Pipe Mount
DFS625HM-A: 12/24V, 6" Lens, Double Flash, w/ Magnetic Mount
DFS625-ACA: 120V AC, Double Flash, w/ Permanent Mount
DFS625P-ACA: 120V AC, Double Flash, w/ Pipe Mount
DFS625H-ACA: 120V AC, 6" Lens, Double Flash, w/ Permanent Mount
Q625-A: 12/24V, Quad Flash, w/ Permanent Mount
Q625F-A: 12/24V, Quad Flash, w/ Permanent Mount w/ Flange Base
Q625P-A: 12/24V, Quad Flash, w/ Pipe Mount
Q625M-A: 12/24V, Quad Flash, w/ Magnetic Mount
Q625H-A: 12/24V, 6" Lens, Quad Flash, w/ Permanent Mount
Q625HF-A: 12/24V, 6" Lens, Quad Flash, Permanent Mount w/ Flange Base
Q625HP-A: 12/24V, 6" Lens, Quad Flash, w/ Pipe Mount
Q625HM-A: 12/24V, 6" Lens, Quad Flash, w/ Magnetic Mount

Item Number	DFS625-A	DFS625H-A	DFS625-ACA	DFS625H-ACA	Q625-A	Q625H-A
Operating Voltage	12/24V	12/24V	120V AC	120V AC	12/24V	12/24V
Rated Current (Amperes)	0.9	0.9	0.2	3	3	3
Light Output (Candelas/Second)	500	800	400	650	825	1200
Joule Rating	10	10	6.25	10	10	10
Flashes per Minute (FPM)	75 Double	75 Double	75 Double	75 Double	75 Quad	75 Quad
Mounting	Permanent, Pipe, or Magnetic	Permanent, Pipe, or Magnetic	Permanent or Pipe	Permanent	Permanent, Permanent w/ Flange Base, Pipe, or Magnetic	Permanent, Permanent w/ Flange Base, Pipe, or Magnetic
Height	4.5"	6.25"	4.5"	6.25"	4.5"	6.25"

Operating voltage at 12/24V
Running a rated current of 0.9 Amperes
Produces 400 to 1,200 candelas/second light output
Features 75 double or quad flashes display
Designed with black ABS plastic base & Fresnel lens
Includes permanent, pipe and magnetic mount
Optional flange base
Available in 5 lens colors

What’s in the Box

North American 625 Series Strobe Warning Light
Instructions and Mounting Guide
75-lb. pull magnet (for models w/ magnetic mount only)
15-inch coiled cord (for models w/ magnetic mount only)
Cigarette lighter plug with a built-in on/off switch (for models w/ magnetic mount only)

Available Product Options

Operating Voltage: 12/24V or 120V AC
Rated Current: 0.2, 0.9, or 3 amperes
Light Output: 400, 500, 650, 800, 825, or 1,200 candelas/second
Flashes per Minute: 75 Double or Quad Flash Display
Joule Rating: 6.5 or 10 joules
Height: 4.5 or 6.25 inches
Mounting: Permanent, Magnetic, Pipe, or Permanent w/ Flange Base
Lens Color: Amber, Blue, Clear, Green or Red

Tiger Supplies offers a 90-day return policy from date of shipment for this product, subject to a 15% to 25% restocking fee, in addition to the return shipping charges. The product must be in new condition and in its original packaging. We take the responsibility to make sure this product arrives in a brand new working condition. Should your item arrive damaged, we will take full responsibility and replace the product at no cost to you.

For complete details of our return policy and process, please refer to our general return policy page.

General

Dimensions

7.000"L x 7.500"W x 6.500"H (DFS625-X, DFS625P-X, DFS625M-X, DFS625-ACX, DFS625P-ACX, Q625-X, Q625F-X, Q625P-X & Q625M-X); 9.000"L x 7.500"W x 8.250"H (DFS625H-X, DFS625HP-X, DFS625HM-X, DFS625H-ACX, Q625H-X, Q625HF-X, Q625HP-X & Q625HM-X)

Materials

Black ABS plastic base; Fresnel lens

Mounting

Permanent (DFS625-X, DFS625H-X, DFS625H-X, DFS625-ACX, DFS625H-ACX, Q625-X & Q625H-X; Pipe (DFS625P-X, DFS625HP-X, DFS625P-ACX, Q625P-X & Q625HP-X); Magnet (DFS625M-X, DFS625HM-X, Q625M-X & Q625HM-X); Permanent w/ Flange Base (Q625F-X & Q625HF-X)

UL Listed

Weight

3.50 lbs (DFS625-X, DFS625P-X, DFS625M-X, DFS625-ACX, DFS625P-ACX, Q625-X, Q625F-X, Q625P-X & Q625M-X); 4.50 (DFS625H-X, DFS625HP-X, DFS625HM-X, DFS625H-ACX, Q625H-X, Q625HF-X, Q625HP-X & Q625HM-X)

Lighting

Color

Amber, Blue, Clear, Green & Red

Flashes per Minute

75 double flash (DFS625-X, DFS625P-X, DFS625M-X, DFS625H-X, DFS625HP-X, DFS625HM-X, DFS625-ACX, DFS625P-ACX & DFS625H-ACX); 75 quad flash (Q625-X, Q625F-X, Q625P-X, Q625M-X, Q625H-X, Q625HF-X, Q625HP-X, Q625HM-X)

Joule Rating - Output Energy

6.25 (DFS625-ACX & DFS625P-ACX); 10 (DFS625-X, DFS625P-X, DFS625M-X, DFS625H-X, DFS625HP-X, DFS625HM-X, DFS625H-ACX, Q625-X, Q625F-X, Q625P-X, Q625M-X, Q625H-X, Q625HF-X, Q625HP-X & Q625HM-X)

Light Output

400 (DFS625-ACX & DFS625P-ACX); 500 (DFS625-X, DFS625P-X & DFS625M-X); 650 (DFS625H-ACX); 800 (DFS625H-X, DFS625HP-X & DFS625HM-X); 825 (Q625-X, Q625F-X, Q625P-X & Q625M-X); 1,200 (Q625H-X, Q625HF-X, Q625HP-X & Q625HM-X)

Rated Current (Ampere)

0.2 (DFS625-ACX & DFS625P-ACX); 3 (DFS625H-ACX, Q625-X, Q625F-X, Q625P-X, Q625M-X, Q625H-X, Q625HF-X, Q625HP-X & Q625HM-X)

Voltage

12/24V (DFS625-X, DFS625P-X, DFS625M-X, DFS625H-X, DFS625HP-X, DFS625HM-X, Q625-X, Q625F-X, Q625P-X, Q625M-X, Q625H-X, Q625HF-X, Q625HP-X & Q625HM-A); 120V AC (DFS625-ACX, DFS625P-ACX & DFS625H-ACX)
